HDB3WHN Serisi

Kutup Sayısı	Anma Akımı (A)	B Eğrisi Kod	C Eğrisi Kod
1 Kutup	1 A	HDB3wHN1B1	HDB3wHN1C1
1 Kutup	2 A	HDB3wHN1B2	HDB3wHN1C2
1 Kutup	3 A	HDB3wHN1B3	HDB3wHN1C3
1 Kutup	4 A	HDB3wHN1B4	HDB3wHN1C4
1 Kutup	6 A	HDB3wHN1B6	HDB3wHN1C6
1 Kutup	10 A	HDB3wHN1B10	HDB3wHN1C10
1 Kutup	16 A	HDB3wHN1B16	HDB3wHN1C16
1 Kutup	20 A	HDB3wHN1B20	HDB3wHN1C20
1 Kutup	25 A	HDB3wHN1B25	HDB3wHN1C25
1 Kutup	32 A	HDB3wHN1B32	HDB3wHN1C32
1 Kutup	40 A	HDB3wHN1B40	HDB3wHN1C40
1 Kutup	50 A	HDB3wHN1B50	HDB3wHN1C50
1 Kutup	63 A	HDB3wHN1B63	HDB3wHN1C63
2 Kutup	2 A	HDB3wHN2B2	HDB3wHN2C2
2 Kutup	6 A	HDB3wHN2B6	HDB3wHN2C6
2 Kutup	10 A	HDB3wHN2B10	HDB3wHN2C10
2 Kutup	16 A	HDB3wHN2B16	HDB3wHN2C16
2 Kutup	20 A	HDB3wHN2B20	HDB3wHN2C20
2 Kutup	25 A	HDB3wHN2B25	HDB3wHN2C25
2 Kutup	32 A	HDB3wHN2B32	HDB3wHN2C32
2 Kutup	40 A	HDB3wHN2B40	HDB3wHN2C40
2 Kutup	50 A	HDB3wHN2B50	HDB3wHN2C50
2 Kutup	63 A	HDB3wHN2B63	HDB3wHN2C63
3 Kutup	2 A	HDB3wHN3B2	HDB3wHN3C2
3 Kutup	6 A	HDB3wHN3B6	HDB3wHN3C6
3 Kutup	10 A	HDB3wHN3B10	HDB3wHN3C10
3 Kutup	16 A	HDB3wHN3B16	HDB3wHN3C16
3 Kutup	20 A	HDB3wHN3B20	HDB3wHN3C20
3 Kutup	25 A	HDB3wHN3B25	HDB3wHN3C25
3 Kutup	32 A	HDB3wHN3B32	HDB3wHN3C32
3 Kutup	40 A	HDB3wHN3B40	HDB3wHN3C40
3 Kutup	50 A	HDB3wHN3B50	HDB3wHN3C50
3 Kutup	63 A	HDB3wHN3B63	HDB3wHN3C63
4 Kutup	2 A	HDB3wHN4B2	HDB3wHN4C2
4 Kutup	6 A	HDB3wHN4B6	HDB3wHN4C6
4 Kutup	10 A	HDB3wHN4B10	HDB3wHN4C10
4 Kutup	16 A	HDB3wHN4B16	HDB3wHN4C16
4 Kutup	20 A	HDB3wHN4B20	HDB3wHN4C20
4 Kutup	25 A	HDB3wHN4B25	HDB3wHN4C25
4 Kutup	32 A	HDB3wHN4B32	HDB3wHN4C32
4 Kutup	40 A	HDB3wHN4B40	HDB3wHN4C40
4 Kutup	50 A	HDB3wHN4B50	HDB3wHN4C50
4 Kutup	63 A	HDB3wHN4B63	HDB3wHN4C63
